Get more control and less mess with the 10-pass concealed bake element. This dual concealed bake element provides finer temperature control and makes oven clean up easy.
Cook for everyone you know and still have leftovers with the largest capacity oven in the industry.
The exclusive SureSpark™ Ignition System ensures automatic ignition/re-ignition should the burners extinguish any time while cooking.
Get the best possible price while shopping at TA Appliance! If you find a lower price we will match and beat it by 10% of the difference for up to 30 days after delivery!
Learn more
Couldn't load pickup availability
Purchase a qualifying Viking Option and receive a FREE Product OR up to a $1000 Allowance!
----PLUS ADD----
A 2nd qualifying Viking Appliance and receive a 2nd FREE Product!
Our team will contact you within 48 hours.
Get more control and less mess with the 10-pass concealed bake element. This dual concealed bake element provides finer temperature control and makes oven clean up easy.
Cook for everyone you know and still have leftovers with the largest capacity oven in the industry.
The exclusive SureSpark™ Ignition System ensures automatic ignition/re-ignition should the burners extinguish any time while cooking.
TruConvec Convection Cooking refers to the exclusive air circulation system employed by Viking convection ovens. Uses only convection element in rear of oven and fan-forced air - no direct heat from top or bottom.
Six porcelain-coated rack positions and comes standard with three oven racks including one TruGlide™ Full Extension Rack.
Maximize air flow and fluffiness with Vari-Speed Dual Flow™ Convection system. Two-speed convection system capable of turning the fan in both directions. This combined with the largest convection fan blades in the industry provides maximum airflow.
The VariSimmer™ Setting on ALL burners provides gentle, even simmering at precisely low cooking temperatures.
Wait less and cook more with the Rapid Ready™ Preheat System. Quick preheat means less time for the user to wait for the oven to be ready to cook in.
Keep spills in one place with the raised edges of our exclusive one-piece tooled porcelainized cooking surface. Raised edges around perimeter seal top to completely contain spills. Porcelanized for easy cleaning, durability and long lasting finish.
| Series Name | 5 Series |
| Fuel Type | Dual Fuel - Natural Gas |
| Installation Type | Freestanding |
| Color | Blue |
| Manufacturer Color | Slate Blue |
Appliance Care • One-Piece Tooled And Porcelainized Cooking Surface for Easy Cleanup • Burner Caps are Easily Removable for Quick Cleaning • Heavy-Duty, Porcelainized, Cast-iron Removable Surface Grates Provide Continuous Front-to-Rear, Left-to-Right Surface for Easy Movement of Large Pots • Self-Cleaning Porcelain Ovens • Concealed Bake Element(S) Make for Easy Cleanup of Oven Cavity |
| Burners/Elements | 4 |
Burners/Elements Output • Front Right TruPower Plus™ Burner: 18,500 BTU • Other Burners: 15,000 BTU | |
| Burners | Sealed |
| Capacity (cu. ft.) | 4.7 cu.ft. |
| Number of Ovens | Single |
Programs High performance cooking modes include: • Bake • Convection Bake • TruConvec™ Convection Cooking • Convection Roast • Hi Broil • Medium Broil • Low Broil • Convection Broil • Convection Dehydrate • Convection Defrost • Self-Clean |
Technologies • VSH™ (VariSimmer-to-High) Pro Sealed Burner System • VariSimmer™ Setting for All Burners • SureSpark™ Ignition System • Vari-Speed Dual Flow™ Convection System • BlackChrome™ Metal Knobs • SoftLit™ LED Lights • GentleClose™ Door • Rapid Ready™ Preheat • TruGlide™ Full Extension Oven Racks | |
| Convection | Yes |
| Oven Light | Yes |
| Self-Cleaning | Yes |
| Automatic Re-Ignition; Surface Burners Light at any Position on the Knob and Re-Light if Extinguished Even on Lowest SettingPatented Vari-Speed Dual Flow™ Convection System; The 8 1/2" Fan Works Bi-Directionally for Maximum Airflow and Excellent Cooking ResultsConcealed 10-Pass Dual Bake Element Provides Precise Temperature ControlLarge 10 Pass Broiler with Heat ReflectorOven Has Six Porcelain Coated Rack Supports and Comes Standard with One Standard Oven Rack and Two Truglide™ Full Extension Oven RacksThree Strategically Located Oven LightsCommercial-Style Bezels Around Control Panel KnobsOne Piece Tooled and Porcelainized Cooking Surface |
Information • 60 Hz • 240 V – 26.8 A • 208 V – 22.8 A |
Optional • BG8530SS – 8"H. Backguard • HS24530SS – High Shelf • P24CSTSS – Countertop Side Trim (2 pieces) • P30CRTSS – Cuntertop Rear Trim • P30CBF4SS – Curb Base and Custom Curb Base Front • LPKPDR – LP/Propane Conversion Kit |
| Class Width | 30" |
| Width | 29.88 inch(es) / 75.9 cm |
| Height | 35.87 inch(es) / 91.1 cm |
| Depth (Without Handles) | 28.03 inch(es) / 71.2 cm |
| Depth (Including Handles) | 28.7 inch(es) / 72.9 cm |
Additional Dimensions Overall Height from Bottom: Base Height • To top of side trim – minimum 35-7/8" (91.1 cm), to maximum 37" (94 cm); legs adjust 1-1/8" (2.9 cm) • Additions to Base Height • To top of island trim – add 1" (2.5 cm); to top of backguard – add 8" (20.3 cm) • To top of high shelf – add 23-1/2" (59.7 cm) Overall Depth from Rear: • To end of side panel – 24-5/16" (61.8 cm); to front of door – 25-3/4" (65.4 cm) Convection Bake/Broil • Overall Width – 25-5/16" (64.6 cm) • Height – 16-1/2" (41.9 cm) • Depth – 19-1/2" (49.5 cm) • AHAM Standard* – 4.1 cu. ft. (*The AHAM Standard for measuring oven capacity subtracts the door plug and convection baffle dimension from the total oven volume) |
| Weight | 409.99 lb(s) / 185.97 kg |
Warranty • Two-Year Full – Complete Product • Ninety-Day Full – Cosmetic Parts Such as Glass, Painted Items, and Decorative Items • Five-Year Limited – All Gas Burners, Electric Elements (Dual Fuel) |
